NEMA24 3.0A 2.6NM 60BYGH89-3004 2phase Hybrid Stepper Motor For Factory Automation
1. Product Description:
Stepping motor is an open-loop control element that converts electrical pulse signals into angular displacement or linear displacement. In the case of non-overload, the motor speed and stop position only depend on the frequency and pulse number of the pulse signal, and are not affected by the load change. When the stepper driver receives a pulse signal, it drives the stepper motor The set direction rotates at a fixed angle, called "step angle", and its rotation runs step by step at a fixed angle. The angular displacement can be controlled by controlling the number of pulses, so as to achieve the purpose of accurate positioning; at the same time, the speed and acceleration of the motor rotation can be controlled by controlling the pulse frequency, so as to achieve the purpose of speed regulation.
2. Specifications
| 60BYGH 2PHASE STEPPER MOTOR |
| MODEL | STEP ANGLE | BODY LENGTH | CURRENT | RESISTANCE | INDUCTANCE | HOLDING TORQUE | POSITIONING TORQUE | MOMENT INERTIA | LEAD NO. | WEIGHT |
| | (.) | L(MM) | (A) | (Ω) | (mH) | (NM) | (NCM) | (GCM2) | | (KG) |
| 60BYGH45-2504 | 1.8 | 45 | 2.5 | 1 | 2.2 | 0.85 | 3 | 200 | 4 | 0.55 |
| 60BYGH56-2504 | 1.8 | 56 | 2.5 | 1.3 | 4.2 | 1.6 | 4 | 350 | 4 | 0.7 |
| 60BYGH56-4204 | 1.8 | 56 | 4.2 | 0.4 | 1.2 | 1.6 | 4 | 350 | 4 | 0.7 |
| 60BYGH65-3004 | 1.8 | 65 | 3 | 0.8 | 2.3 | 1.8 | 5 | 450 | 4 | 0.85 |
| 60BYGH65-4204 | 1.8 | 65 | 4.2 | 0.55 | 1.2 | 1.8 | 5 | 450 | 4 | 0.85 |
| 60BYGH76-2504 | 1.8 | 76 | 2.5 | 1.8 | 6.5 | 2.2 | 7 | 550 | 4 | 1.15 |
| 60BYGH76-3004 | 1.8 | 76 | 3 | 1 | 3.5 | 2.2 | 7 | 550 | 4 | 1.15 |
| 60BYGH76-4204 | 1.8 | 76 | 4.2 | 0.6 | 1.8 | 2.2 | 7 | 550 | 4 | 1.15 |
| 60BYGH89-3004 | 1.8 | 89 | 3 | 1.4 | 5.5 | 2.6 | 12 | 780 | 4 | 1.4 |
| 60BYGH89-4204 | 1.8 | 89 | 4.2 | 0.7 | 2.8 | 2.6 | 12 | 780 | 4 | 1.4 |
| 60BYGH100-4204 | 1.8 | 100 | 4.2 | 0.7 | 3 | 3 | 16 | 900 | 4 | 1.6 |
| 60BYGH112-4204 | 1.8 | 112 | 4.2 | 0.85 | 3.5 | 3.6 | 16 | 900 | 4 | 1.8 |
3. What is a NEMA 24 motor?
A series of stepper motors with flange 60mmx60mm (also known as NEMA24), slightly larger than the most common NEMA23.The larger internal rotor allows to improve the performance of the application when the load is highly inertial, as it improves the inertia relation between the motor and the load itself.
The frame size difference of the NEMA 23 and 24 is very slight and, depending on the motor mount both will most likely fit. The bigger difference between these stepping motors is the torque. Make sure that the motor that you purchase has the appropriate torque for the axis that it will move. Is is safe to go with the higher torque? Or if the torque is too high for what i need is that bad? You can use a motor with higher torque. Just make sure to select the correct driver for that motor.
Choosing the correct motor for your application can be tricky. If you have any doubts please contact us. We will help you find the best motor for your application even if it is one we don't sell. If you want to buy NEMA 24 stepper motor,Our store is definitely your best choice.Our Stepper motor technology utilizes a simple design to create an effective solution for many applications requiring reasonable accuracy and torque. Get a stepper motor that meets your requirements precisely. Shop with confidence!
Production equipment:
5. Related Qualification Certificate:
6. FAQ
Q1: Are you manufacturer ?
A1: Yes, we are the manufacturer of gear motor and planetary gearbox.
Q2 : What specifications we need before you place an order?
A2 : Rated torque, Rated speed, IP Grade, mounting dimensions.
Q3 : What is the price ?
A3 : Price always depends on quantity, we offer range pricing
Q4 : Is it customized ?
A4 : Yes, different clients have different requirements, so we customize for you. .
